Home > Products > Integrated Circuits (ICs) > PMIC - AC DC Converters, Offline Switchers > TOP223YN

TOP223YN

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TOP223YN with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	TOP223YN
Manufacturer	Power Integrations
Description	IC OFFLINE SWIT PWM OCP HV TO220
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	500 pcs	1000 pcs	2500 pcs	5000 pcs
~~In Stock~~ 50245 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	50 pcs	100 pcs	250 pcs
	$1.498	$1.337	$1.203	$1.096	$0.989
	$0.888	$0.749	$0.711	$0.684

Product parameter
Data sheet

Product parameter

Part Number	TOP223YN	Manufacturer	Power Integrations
Description	IC OFFLINE SWIT PWM OCP HV TO220	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	50245 pcs	Data sheet	TOP221 - 227
Category	Integrated Circuits (ICs)	Voltage - Supply (Vcc/Vdd)	-
Voltage - Breakdown	700V	Topology	Boost, Buck, Flyback, Forward
Supplier Device Package	TO-220-3	Series	TOPSwitch®-II
Power (Watts)	50W	Packaging	Tube
Package / Case	TO-220-3	Output Isolation	Isolated
Other Names	596-1158-5 TOP223YN-ND	Operating Temperature	-40°C ~ 150°C (TJ)
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Internal Switch(s)	Yes
Frequency - Switching	100kHz	Fault Protection	Current Limiting, Over Temperature
Duty Cycle	67%	Detailed Description	Converter Offline Boost, Buck, Flyback, Forward Topology 100kHz TO-220-3
Control Features	-
