RDK-506
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RDK-506 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy RDK-506 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | RDK-506 |
|---|---|
| Manufacturer | Power Integrations |
| Description | KIT REF DESIGN LINKSWITCH-TN2 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $34.405 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | RDK-506 | Manufacturer | Power Integrations |
|---|---|---|---|
| Description | KIT REF DESIGN LINKSWITCH-TN2 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 878 pcs | Data sheet | LNK3202, LNK3204-06RDR-506 |
| Category | Development Boards, Kits, Programmers | Voltage - Output | 12V |
| Voltage - Input | 85 ~ 265 VAC | Utilized IC / Part | LNK3204D |
| Supplied Contents | Board(s) | Series | LinkSwitch®-TN2 |
| Regulator Topology | Flyback | Power - Output | 1.44W |
| Outputs and Type | 1, Non-Isolated | Other Names | 596-1593 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 16 Weeks |
| Main Purpose | AC/DC, Primary Side | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Frequency - Switching | - | Detailed Description | LNK3204D LinkSwitch®-TN2 AC/DC, Primary Side 1, Non-Isolated Outputs Evaluation Board |
| Current - Output | 120mA | Board Type | Fully Populated |
