Home > Products > Integrated Circuits (ICs) > PMIC - PFC (Power Factor Correction) > PFS7536H

PFS7536H

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PFS7536H with confidence from Components-World.HK, 1 Year Warranty

Dowload PFS7536H Details in PDF

Request a Quote

Part Number	PFS7536H
Manufacturer	Power Integrations
Description	IC PFC CTLR 610W 180VAC 16ESIP
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 28378 pcs
Reference Price (In US Dollars)	180 pcs
Reference Price (In US Dollars)	$1.139

Product parameter
Data sheet

Product parameter

Part Number	PFS7536H	Manufacturer	Power Integrations
Description	IC PFC CTLR 610W 180VAC 16ESIP	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	28378 pcs	Data sheet	HiperPFS-3 Family
Category	Integrated Circuits (ICs)	Voltage - Supply	10.2 V ~ 15 V
Supplier Device Package	eSIP-16D	Series	HiperPFS™
Packaging	Tube	Package / Case	16-SSIP, 13 Leads, Exposed Pad, Formed Leads
Operating Temperature	-40°C ~ 150°C	Mounting Type	Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Mode	Continuous Conduction (CCM)
Manufacturer Standard Lead Time	16 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Frequency - Switching	22kHz ~ 123kHz	Detailed Description	PFC IC Continuous Conduction (CCM) 22kHz ~ 123kHz eSIP-16D
