Home > Products > Integrated Circuits (ICs) > PMIC - Gate Drivers > 2SD106AI-17 UL

2SD106AI-17 UL

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 2SD106AI-17 UL with confidence from Components-World.HK, 1 Year Warranty

Dowload 2SD106AI-17 UL Details in PDF

Request a Quote

Part Number	2SD106AI-17 UL
Manufacturer	Power Integrations
Description	IC DUAL GATE DRIVER 6A
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 1317 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	40 pcs	100 pcs
Reference Price (In US Dollars)	$37.237	$31.652	$29.789	$26.067

Product parameter
Data sheet

Product parameter

Part Number	2SD106AI-17 UL	Manufacturer	Power Integrations
Description	IC DUAL GATE DRIVER 6A	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	1317 pcs	Data sheet	2SD106AI-17 UL
Category	Integrated Circuits (ICs)	Voltage - Supply	15V
Supplier Device Package	Module	Series	SCALE™-1
Rise / Fall Time (Typ)	100ns, 80ns	Packaging	Tray
Package / Case	Module	Other Names	1810-1000
Operating Temperature	-40°C ~ 85°C (TA)	Number of Drivers	2
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Logic Voltage - VIL, VIH	-	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Input Type	-	Gate Type	IGBT, N-Channel, P-Channel MOSFET
Driven Configuration	Half-Bridge	Detailed Description	Half-Bridge Gate Driver IC Module
Current - Peak Output (Source, Sink)	6A, 6A	Channel Type	-
