15M020D1B-N
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 15M020D1B-N with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 15M020D1B-N with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 15M020D1B-N |
|---|---|
| Manufacturer | Portescap |
| Description | STEPPER MOTOR PM BIPOLAR 5V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 100 pcs | ||||
|---|---|---|---|---|---|
| $6.678 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 15M020D1B-N | Manufacturer | Portescap |
|---|---|---|---|
| Description | STEPPER MOTOR PM BIPOLAR 5V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5326 pcs | Data sheet | 15M020D SeriesCanStack Motor Part Numbering15M Series Wiring Diagram |
| Category | Motors, Solenoids, Driver Boards/Modules | Weight | 0.031 lb (14.06g) |
| Voltage - Rated | 5VDC | Type | Permanent Magnet |
| Torque - Holding (oz-in / mNm) | 0.55 / 3.9 | Termination Style | Wire Leads |
| Steps per Revolution | 20 | Step Angle | 18° |
| Size / Dimension | Round - 0.610" Dia (15.50mm) | Series | 15M |
| Rotor Inertia | 0.115gcm² | Other Names | 15020D1B-N 15M020D1B 403-1000 |
| Operating Temperature | -20°C ~ 70°C | Mounting Hole Spacing | 0.787" (20.00mm) |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Length - Shaft and Bearing | 0.394" (10.00mm) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | Round Shaft |
| Diameter - Shaft | 0.059" (1.50mm) | Detailed Description | Bipolar Stepper Motor 125mA 5VDC |
| Current Rating | 125mA | Coil Type | Bipolar |
| Coil Resistance | 40 Ohms | Approvals | - |
| Accuracy | - |
