1790564
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1790564 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1790564 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1790564 |
|---|---|
| Manufacturer | Phoenix Contact |
| Description | TERM BLOCK PLUG 20POS STR 3.5MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | ||
|---|---|---|---|---|---|
| $5.792 | $5.632 | $5.263 | |||
| 100 pcs | 250 pcs | 500 pcs | |||
| $4.842 | $4.474 | $4.263 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1790564 | Manufacturer | Phoenix Contact |
|---|---|---|---|
| Description | TERM BLOCK PLUG 20POS STR 3.5MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 7388 pcs | Data sheet | 1790564 |
| Category | Connectors, Interconnects | Wire Strip Length | 10mm |
| Wire Gauge or Range - mm² | 0.2-1.5mm² | Wire Gauge or Range - AWG | 16-24 AWG |
| Voltage - UL | 150V | Voltage - IEC | 250V |
| Type | Plug, Female Sockets | Torque - Screw | - |
| Termination Style | Screwless - Push-In Spring | Series | COMBICON DFMC |
| Screw Size | - | Positions Per Level | 10 |
| Plug Wire Entry | 180° | Pitch | 0.138" (3.50mm) |
| Packaging | Bulk | Other Names | 1790564-ND 277-8803 DFMC1,5/10-ST-3,5-LR DFMC1510ST35LR |
| Operating Temperature | - | Number of Positions | 20 |
| Number of Levels | 2 | Mounting Type | Free Hanging (In-Line) |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 2 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Height | 0.522" (13.25mm) | Ingress Protection | - |
| Housing Material | Polyamide (PA), Nylon | Header Orientation | - |
| Features | Ejector Latches | Detailed Description | 20 Position Terminal Block Plug, Female Sockets 0.138" (3.50mm) 180° Free Hanging (In-Line) |
| Current - UL | 8A | Current - IEC | 8A |
| Contact Tail Length | - | Contact Mating Finish | Tin |
| Contact Material | - | Color | Green |
