1757501
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1757501 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1757501 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1757501 |
|---|---|
| Manufacturer | Phoenix Contact |
| Description | TERM BLOCK HDR 5POS 90DEG 5MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | 100 pcs | 250 pcs |
|---|---|---|---|---|---|
| $0.61 | $0.584 | $0.559 | $0.543 | $0.508 | |
| 500 pcs | 1000 pcs | 2500 pcs | 5000 pcs | ||
| $0.467 | $0.423 | $0.403 | $0.378 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1757501 | Manufacturer | Phoenix Contact |
|---|---|---|---|
| Description | TERM BLOCK HDR 5POS 90DEG 5MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 91157 pcs | Data sheet | 1757501 |
| Category | Connectors, Interconnects | Wire Strip Length | - |
| Wire Gauge or Range - mm² | - | Wire Gauge or Range - Coaxial | - |
| Voltage - UL | 15A | Voltage - IEC | 12A |
| Voltage - DC Spark Over (Nom) | - | Type Attributes | - |
| Type | Header, Male Pins, Shrouded (4 Side) | Torque - Screw | Tin |
| Termination Style | Solder | Terminal - Width | 1 |
| Series | COMBICON MSTBA | RoHS Status | Bulk |
| Plug Wire Entry | 90°, Right Angle | Other Names | 277-1120 MSTBA 2.5/5-G MSTBA2,5/5-G |
| Operating Temperature | - | Number of Positions | 5 |
| Number of Conductors | 0.197" (5.00mm) | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 5 Weeks | Manufacturer Part Number | 1757501 |
| Header Orientation | 5 | Front Panel Wire Connection | 0.138" (3.50mm) |
| Filter Type | 300V | Features | - |
| Expanded Description | 5 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.197" (5.00mm) 90°, Right Angle Through Hole | Description | TERM BLOCK HDR 5POS 90DEG 5MM |
| Current - UL | 400V | Contact Tail Length | - |
| Contact Mating Finish | - | Contact Finish - Mating | 0.339" (8.61mm) |
| Color | Green | Cable Opening | Polyamide (PA), Nylon |
| Bundle Center to Mounting Center | - |
