1725120
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1725120 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1725120 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1725120 |
|---|---|
| Manufacturer | Phoenix Contact |
| Description | TERM BLOCK PLUG 3POS 45DEG 3.5MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $0.463 | $0.444 | $0.425 | $0.414 | ||
| 250 pcs | 500 pcs | 1000 pcs | |||
| $0.387 | $0.356 | $0.329 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1725120 | Manufacturer | Phoenix Contact |
|---|---|---|---|
| Description | TERM BLOCK PLUG 3POS 45DEG 3.5MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 68025 pcs | Data sheet | 1725120 Datasheet1725120 |
| Category | Connectors, Interconnects | Wire Strip Length | 10mm |
| Wire Gauge or Range - mm² | 0.2-1.5mm² | Wire Gauge or Range - AWG | 16-24 AWG |
| Voltage - UL | 300V | Voltage - IEC | 400V |
| Type | Plug for Unshrouded Header | Torque - Screw | - |
| Termination Style | Screwless - Spring Cage, Tension Clamp | Series | COMBICON PTDA |
| Screw Size | - | Positions Per Level | 3 (Mate), 6 (Input) |
| Plug Wire Entry | 45° | Pitch | 0.138" (3.50mm) |
| Packaging | Bulk | Other Names | 1725120-ND 277-13802 PTDA1,5/3-PH-3,5 |
| Operating Temperature | - | Number of Positions | 3 |
| Number of Levels | 1 (Mate), 2 (Input) | Mounting Type | Free Hanging (In-Line) |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 4 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Height | 0.630" (16.00mm) | Ingress Protection | - |
| Housing Material | Polyamide (PA), Nylon | Header Orientation | - |
| Features | - | Detailed Description | 3 Position Terminal Block Plug for Unshrouded Header 0.138" (3.50mm) 45° Free Hanging (In-Line) |
| Current - UL | 10A | Current - IEC | 8A |
| Contact Tail Length | - | Contact Mating Finish | Tin |
| Contact Material | - | Color | Green |
