1720505
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1720505 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1720505 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1720505 |
|---|---|
| Manufacturer | Phoenix Contact |
| Description | TERM BLOCK HDR 6POS 90DEG 7.62MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $3.165 | $3.077 | $2.876 | $2.646 | ||
| 250 pcs | 500 pcs | 1000 pcs | |||
| $2.444 | $2.329 | $2.186 | |||
- Product parameter
Product parameter
| Part Number | 1720505 | Manufacturer | Phoenix Contact |
|---|---|---|---|
| Description | TERM BLOCK HDR 6POS 90DEG 7.62MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 14007 pcs | Data sheet | |
| Category | Connectors, Interconnects | Wire Strip Length | - |
| Wire Gauge or Range - mm² | - | Wire Gauge or Range - AWG | - |
| Voltage - UL | 300V | Voltage - IEC | 1kV |
| Type | Header, Male Pins, Shrouded (4 Side) | Torque - Screw | - |
| Termination Style | Solder | Series | COMBICON PC |
| Screw Size | - | Positions Per Level | 6 |
| Plug Wire Entry | - | Pitch | 0.300" (7.62mm) |
| Packaging | Bulk | Other Names | 1720505-ND 277-6961 PC 5/ 6-G-7,62 PC5/6-G-7,62 |
| Operating Temperature | - | Number of Positions | 6 |
| Number of Levels | 1 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 2 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Height | 0.563" (14.30mm) | Ingress Protection | - |
| Housing Material | Polyamide (PA), Nylon | Header Orientation | 90°, Right Angle |
| Features | Latch Lock | Detailed Description | 6 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.300" (7.62mm) 90°, Right Angle Through Hole |
| Current - UL | 41A | Current - IEC | 41A |
| Contact Tail Length | 0.197" (5.00mm) | Contact Mating Finish | Tin |
| Contact Material | - | Color | Green |
