1715264
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1715264 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1715264 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1715264 |
|---|---|
| Manufacturer | Phoenix Contact |
| Description | TERM BLOCK PLUG 3POS STR 10.16MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | ||
|---|---|---|---|---|---|
| $8.415 | $8.184 | $7.649 | |||
| 100 pcs | 250 pcs | 500 pcs | |||
| $7.037 | $6.502 | $6.196 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1715264 | Manufacturer | Phoenix Contact |
|---|---|---|---|
| Description | TERM BLOCK PLUG 3POS STR 10.16MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5905 pcs | Data sheet | 1715264 Datasheet |
| Category | Connectors, Interconnects | Wire Strip Length | 18mm |
| Wire Gauge or Range - mm² | 0.75-16mm² | Wire Gauge or Range - AWG | 4-20 AWG |
| Voltage - UL | 600V | Voltage - IEC | 1kV |
| Type | Plug, Female Sockets | Torque - Screw | 1.7-1.8 Nm (15-15.9 Lb-In) |
| Termination Style | Screw - Clamping Yoke (Tension Sleeve) | Series | COMBICON TPC |
| Screw Size | M4 | Positions Per Level | 3 (Mate), 6 (Input) |
| Plug Wire Entry | 180° | Pitch | 0.400" (10.16mm) |
| Packaging | Bulk | Other Names | 1715264-ND 277-13761 TPC16/3-STF-10,16 TPC163STF1016 |
| Operating Temperature | - | Number of Positions | 3 |
| Number of Levels | 1 (Mate), 2 (Input) | Mounting Type | Free Hanging (In-Line) |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 4 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Height | 2.024" (51.40mm) | Ingress Protection | - |
| Housing Material | Polyamide (PA), Nylon | Header Orientation | - |
| Features | Mating Flange | Detailed Description | 3 Position Terminal Block Plug, Female Sockets 0.400" (10.16mm) 180° Free Hanging (In-Line) |
| Current - UL | 60A | Current - IEC | 76A |
| Contact Tail Length | - | Contact Mating Finish | Silver |
| Contact Material | - | Color | Green |
