1688120
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1688120 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1688120 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1688120 |
|---|---|
| Manufacturer | Phoenix Contact |
| Description | CONN D-SUB RCPT 15POS R/A SOLDER |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $6.549 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1688120 | Manufacturer | Phoenix Contact |
|---|---|---|---|
| Description | CONN D-SUB RCPT 15POS R/A SOLDER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5645 pcs | Data sheet | VARIOSUB D-Sub 15 |
| Category | Connectors, Interconnects | Wire Gauge | - |
| Voltage Rating | 125V | Termination | Solder |
| Shell Size, Connector Layout | 2 (DA, A) | Shell Material, Finish | Steel, Yellow Chromate Plated |
| Series | PLUSCON | Packaging | Bulk |
| Other Names | VS-15-BU-DSUB-ER VS15BUDSUBER |
Operating Temperature | -55°C ~ 125°C |
| Number of Rows | 2 | Number of Positions | 15 |
| Mounting Type | Through Hole, Right Angle | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Manufacturer Standard Lead Time | 3 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Housing Material | Polyester, Glass Filled | Flange Feature | Housing/Shell (M3) |
| Features | Board Lock, Mounting Brackets | Detailed Description | 15 Position D-Sub Receptacle, Female Sockets Connector |
| Current Rating | 5A | Contact Type | Signal |
| Contact Material | Copper Alloy | Contact Form | - |
| Contact Finish Thickness | - | Contact Finish | Gold |
| Connector Type | Receptacle, Female Sockets | Connector Style | D-Sub |
| Color | - | Backset Spacing | 0.370" (9.40mm) |
