Home > Products > Connectors, Interconnects > Heavy Duty Connectors - Housings, Hoods, Bases > 1604785

1604785

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1604785 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	1604785
Manufacturer	Phoenix Contact
Description	CONN BASE SIDE ENTRY SZB16 M25
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 2926 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$13.349

Product parameter
Data sheet

Product parameter

Part Number	1604785	Manufacturer	Phoenix Contact
Description	CONN BASE SIDE ENTRY SZB16 M25	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	2926 pcs	Data sheet	1604785
Category	Connectors, Interconnects	Thread Size	M25
Style	Side Entry	Size / Dimension	4.606" L x 2.244" W x 2.638" H (117.00mm x 57.00mm x 67.00mm)
Size	B16	Series	HEAVYCON® B
Packaging	Bulk	Other Names	1604785-ND 277-8440 HC-B16-SML-67/O2M25 HCB16SML67O2M25
Operating Temperature	-40°C ~ 125°C	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	2 Weeks	Lock Location	Locking Clip (1) on Base Bottom
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	IP65 - Dust Tight, Water Resistant
Housing Material	Aluminum, Die Cast	Housing Finish	Powder Coated
Housing Color	Gray	Features	Feed Through
Connector Type	Base - Box Mount
