PN18-6R-3K
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PN18-6R-3K with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PN18-6R-3K with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PN18-6R-3K |
|---|---|
| Manufacturer | Panduit |
| Description | CONN RING CIRC 18-22AWG #6 CRIMP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $0.17 | $0.167 | $0.164 | $0.16 | ||
| 100 pcs | 500 pcs | 1000 pcs | |||
| $0.156 | $0.152 | $0.141 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | PN18-6R-3K | Manufacturer | Panduit |
|---|---|---|---|
| Description | CONN RING CIRC 18-22AWG #6 CRIMP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 150205 pcs | Data sheet | PN18-R DrawingTerminal Part Number System |
| Category | Connectors, Interconnects | Wire Gauge | 18-22 AWG |
| Width - Outer Edges | 0.250" (6.35mm) | Thickness | 0.031" (0.79mm) |
| Termination | Crimp | Terminal Type | Circular |
| Stud/Tab Size | 6 Stud | Series | Pan-Term® |
| Packaging | Cut Tape (CT) | Other Names | 298-11480-1 |
| Mounting Type | Free Hanging (In-Line) | Moisture Sensitivity Level (MSL) | Not Applicable |
| Material - Insulation | Polyamide (PA), Nylon | Manufacturer Standard Lead Time | 4 Weeks |
| Length - Overall | 0.780" (19.81mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Diameter | 0.080" ~ 0.145" (2.03mm ~ 3.68mm) | Insulation | Insulated |
| Features | Serrated Termination | Detailed Description | Ring Terminal Connector 6 Stud Circular 18-22 AWG Crimp |
| Contact Material | Copper | Contact Finish | Tin |
| Color | Red |
