LCB2-56-Q
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy LCB2-56-Q with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy LCB2-56-Q with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | LCB2-56-Q |
|---|---|
| Manufacturer | Panduit |
| Description | CONN TERM RECT TONG 2 AWG #5/16 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $3.304 | $3.215 | $3.125 | $3.036 | ||
| 100 pcs | 500 pcs | 1000 pcs | |||
| $2.947 | $2.857 | $2.768 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | LCB2-56-Q | Manufacturer | Panduit |
|---|---|---|---|
| Description | CONN TERM RECT TONG 2 AWG #5/16 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 12135 pcs | Data sheet | LCB2-56-Q Drawing |
| Category | Connectors, Interconnects | Wire Gauge | 2 AWG |
| Width - Outer Edges | 0.660" (16.76mm) | Termination | Crimp, Barrel |
| Terminal Type | Rectangular Tongue | Terminal Style | Single Stud Hole |
| Tab Thickness | 0.100" (2.54mm) | Stud/Tab Size | 5/16 Stud |
| Series | Pan-Lug® | Packaging | Bulk |
| Other Names | 07498390181 298-14771 LCB2-56-Q-ND |
Mounting Type | Free Hanging (In-Line) |
| Moisture Sensitivity Level (MSL) | Not Applicable | Manufacturer Standard Lead Time | 4 Weeks |
| Length - Overall | 2.270" (57.66mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation | Non-Insulated | Features | - |
| Diameter - Ring ID | 0.340" (8.64mm) | Diameter - Barrel OD | 0.420" (10.67mm) |
| Diameter - Barrel ID | 0.310" (7.87mm) | Detailed Description | Terminal Connector Rectangular Rectangular Tongue 2 AWG 5/16 Stud |
| Contact Material | Copper | Contact Finish | Electro-Tin |
| Color | Brown |
