SP4-P-DC24V
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SP4-P-DC24V with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SP4-P-DC24V with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SP4-P-DC24V |
|---|---|
| Manufacturer | Panasonic |
| Description | RELAY GEN PURPOSE 4PDT 10A 24V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $11.108 | $10.553 | $9.998 | |||
| 50 pcs | 100 pcs | 250 pcs | |||
| $9.442 | $8.887 | $8.331 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | SP4-P-DC24V | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY GEN PURPOSE 4PDT 10A 24V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4176 pcs | Data sheet | SP Series |
| Category | Relays | Turn On Voltage (Max) | 16.8 VDC |
| Turn Off Voltage (Min) | 2.4 VDC | Termination Style | PC Pin |
| Switching Voltage | 250VAC, 30VDC - Max | Series | SP |
| Release Time | 20ms | Relay Type | General Purpose |
| Packaging | Tube | Other Names | 255-3457 SP4-P-DC24V-ND SP4PDC24V |
| Operating Temperature | -50°C ~ 60°C | Operate Time | 30ms |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 10 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | - | Detailed Description | General Purpose Relay 4PDT (4 Form C) 24VDC Coil Through Hole |
| Contact Rating (Current) | 10A | Contact Material | Silver Tin Oxide (AgSnO) |
| Contact Form | 4PDT (4 Form C) | Coil Voltage | 24VDC |
| Coil Type | Non Latching | Coil Resistance | 1.92 kOhms |
| Coil Power | 300 mW | Coil Current | 12.5mA |
