Home > Products > Motors, Solenoids, Driver Boards/Modules > Motor Driver Boards, Modules > MCDKT3520

MCDKT3520

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MCDKT3520 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	MCDKT3520
Manufacturer	Panasonic
Description	SERVO DRIVER 30A 240V LOAD
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 148 pcs
Reference Price (In US Dollars)	1 pcs	5 pcs	10 pcs
Reference Price (In US Dollars)	$231.433	$227.299	$223.167

Product parameter
Data sheet

Product parameter

Part Number	MCDKT3520	Manufacturer	Panasonic
Description	SERVO DRIVER 30A 240V LOAD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	148 pcs	Data sheet	E Series MINAS Catalog
Category	Motors, Solenoids, Driver Boards/Modules	Weight	3.6 lbs (1.6kg)
Wattage - Load	750W	Voltage - Supply	200 ~ 240VAC
Voltage - Load	240 V	Type	Module
Series	MINAS A5II	Other Names	1110-3790
Operating Temperature	0°C ~ 55°C	Number of Motors	1
Mounting Type	Chassis Mount	Motor Type	Servo
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	11 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Interface	RS-232, RS-485, USB
For Use With/Related Products	MINAS A5 Series	Features	-
Detailed Description	Servo AC 200 ~ 240VAC Supply 30A 240 V Load	Current - Output	30A
Control / Drive Type	Servo AC
