LNJ757W86RA
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy LNJ757W86RA with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy LNJ757W86RA with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | LNJ757W86RA |
|---|---|
| Manufacturer | Panasonic |
| Description | LED RGB CHIP 628NM 525 470NM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 5000 pcs | ||||
|---|---|---|---|---|---|
| $0.178 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | LNJ757W86RA | Manufacturer | Panasonic |
|---|---|---|---|
| Description | LED RGB CHIP 628NM 525 470NM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 125850 pcs | Data sheet | LNJ757W86RA |
| Category | Optoelectronics | Wavelength - Peak | 643nm Red, 520nm Green, 462nm Blue |
| Wavelength - Dominant | 628nm Red, 525nm Green, 470nm Blue | Voltage - Forward (Vf) (Typ) | 1.9V Red, 3V Green, 2.95V Blue |
| Viewing Angle | - | Supplier Device Package | Chip LED |
| Size / Dimension | 1.30mm L x 1.05mm W | Series | - |
| Packaging | Tape & Reel (TR) | Package / Case | 4-SMD, No Lead |
| Other Names | P16825TR | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | Millicandela Rating | 30mcd Red, 90mcd Green, 15mcd Blue |
| Lens Transparency | - | Lens Style/Size | Rectangle with Flat Top, 1.30mm x 0.70mm |
| Lens Color | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height (Max) | 0.35mm | Features | - |
| Detailed Description | Red, Green, Blue (RGB) 628nm Red, 525nm Green, 470nm Blue LED Indication - Discrete 1.9V Red, 3V Green, 2.95V Blue 4-SMD, No Lead | Current - Test | 5mA Red, 5mA Green, 5mA Blue |
| Configuration | Common Anode | Color | Red, Green, Blue (RGB) |
| Base Part Number | LNJ757 |
