JSM1AF-12V-4
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy JSM1AF-12V-4 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy JSM1AF-12V-4 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | JSM1AF-12V-4 |
|---|---|
| Manufacturer | Panasonic |
| Description | RELAY AUTOMOTIVE SPST 10A 12V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 100 pcs | ||||
|---|---|---|---|---|---|
| $0.591 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | JSM1AF-12V-4 | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY AUTOMOTIVE SPST 10A 12V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 59525 pcs | Data sheet | JS-M Series Datasheet |
| Category | Relays | Turn On Voltage (Max) | 6.3 VDC |
| Turn Off Voltage (Min) | 0.9 VDC | Termination Style | PC Pin |
| Switching Voltage | 16VDC - Max | Series | JS-M |
| Release Time | 10ms | Packaging | Bulk |
| Operating Temperature | -40°C ~ 85°C | Operate Time | 10ms |
| Mounting Type | Through Hole | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | Sealed - Flux Protection |
| Contact Rating (Current) | 10A | Contact Material | Silver Alloy, Cadmium Free |
| Contact Form | SPST-NO (1 Form A) | Coil Voltage | 12VDC |
| Coil Type | Non Latching | Coil Resistance | 225 Ohms |
| Coil Power | 640 mW | Coil Current | 53.3mA |
