JQ1-48V-F
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy JQ1-48V-F with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy JQ1-48V-F with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | JQ1-48V-F |
|---|---|
| Manufacturer | Panasonic |
| Description | RELAY GEN PURPOSE SPDT 5A 48V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.642 | $1.539 | $1.368 | $1.30 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.231 | $1.094 | $1.026 | $0.958 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | JQ1-48V-F | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY GEN PURPOSE SPDT 5A 48V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 37893 pcs | Data sheet | JQ Series |
| Category | Relays | Turn On Voltage (Max) | 36 VDC |
| Turn Off Voltage (Min) | 2.4 VDC | Termination Style | PC Pin |
| Switching Voltage | 250VAC, 110VDC - Max | Series | JQ |
| Release Time | 10ms | Relay Type | General Purpose |
| Packaging | Bulk | Other Names | 255-6171 JQ1-48V-F-ND |
| Operating Temperature | -40°C ~ 70°C | Operate Time | 20ms |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | Insulation - Class E | Detailed Description | General Purpose Relay SPDT (1 Form C) 48VDC Coil Through Hole |
| Contact Rating (Current) | 5A | Contact Material | Silver Tin Oxide (AgSnO) |
| Contact Form | SPDT (1 Form C) | Coil Voltage | 48VDC |
| Coil Type | Non Latching | Coil Resistance | 5.76 kOhms |
| Coil Power | 400 mW | Coil Current | 8.3mA |
