HL1-HTM-DC24V-F
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HL1-HTM-DC24V-F with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HL1-HTM-DC24V-F with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HL1-HTM-DC24V-F |
|---|---|
| Manufacturer | Panasonic |
| Description | RELAY GEN PURPOSE SPDT 15A 24V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 20 pcs | 40 pcs | 60 pcs | |
|---|---|---|---|---|---|
| $4.008 | $3.756 | $3.339 | $3.172 | ||
| 100 pcs | 260 pcs | 500 pcs | |||
| $3.005 | $2.671 | $2.504 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | HL1-HTM-DC24V-F | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY GEN PURPOSE SPDT 15A 24V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 13719 pcs | Data sheet | HL Relay Datasheet |
| Category | Relays | Turn On Voltage (Max) | 19.2 VDC |
| Turn Off Voltage (Min) | 2.4 VDC | Termination Style | Quick Connect - 0.187" (4.7mm) |
| Switching Voltage | 125VAC - Nom | Series | HL |
| Release Time | 25ms | Relay Type | General Purpose |
| Packaging | Tube | Other Names | 255-3347 HL1HTMDC24VF |
| Operating Temperature | -50°C ~ 70°C | Operate Time | 25ms |
| Mounting Type | Chassis Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | - |
| Detailed Description | General Purpose Relay SPDT (1 Form C) 24VDC Coil Chassis Mount | Contact Rating (Current) | 15A |
| Contact Material | Silver Tin Oxide (AgSnO) | Contact Form | SPDT (1 Form C) |
| Coil Voltage | 24VDC | Coil Type | Non Latching |
| Coil Resistance | 650 Ohms | Coil Power | 900 mW |
| Coil Current | 37.0mA |
