HE1AN-SW-DC12V
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HE1AN-SW-DC12V with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HE1AN-SW-DC12V with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HE1AN-SW-DC12V |
|---|---|
| Manufacturer | Panasonic |
| Description | RELAY GEN PURPOSE SPST 30A 12V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | HE1AN-SW-DC12V | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY GEN PURPOSE SPST 30A 12V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5611 pcs | Data sheet | HE Series Datasheet |
| Category | Relays | Turn On Voltage (Max) | 8.4 VDC |
| Turn Off Voltage (Min) | 1.2 VDC | Termination Style | Screw Terminal |
| Switching Voltage | 277VAC, 30VDC - Max | Series | HE |
| Release Time | 10ms | Relay Type | General Purpose |
| Packaging | Bulk | Other Names | 255-1656 HE1ANSWDC12V |
| Operating Temperature | -50°C ~ 55°C | Operate Time | 30ms |
| Mounting Type | Chassis Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | - |
| Detailed Description | General Purpose Relay SPST-NO (1 Form A) 12VDC Coil Chassis Mount | Contact Rating (Current) | 30A |
| Contact Material | Silver Tin Oxide (AgSnO) | Contact Form | SPST-NO (1 Form A) |
| Coil Voltage | 12VDC | Coil Type | Non Latching |
| Coil Resistance | 75 Ohms | Coil Power | 1.92 W |
| Coil Current | 160mA |
