EVQ-Q3AA15
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy EVQ-Q3AA15 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy EVQ-Q3AA15 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | EVQ-Q3AA15 |
|---|---|
| Manufacturer | Panasonic |
| Description | SWITCH NAVIG TACTILE 20MA 15V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $0.962 | $0.925 | $0.851 | $0.74 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $0.703 | $0.684 | $0.666 | $0.518 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | EVQ-Q3AA15 | Manufacturer | Panasonic |
|---|---|---|---|
| Description | SWITCH NAVIG TACTILE 20MA 15V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 67410 pcs | Data sheet | EVQQ3 |
| Category | Switches | Voltage Rating - DC | 15V |
| Voltage - Supply | - | Type | Navigation Switch, 2 - Axis |
| Termination Style | J Lead | Switch Function | 4-Way Directional, Center Select |
| Series | EVQQ3 | Panel Cutout Dimensions | - |
| Output | Digital (Mechanical Switch) | Other Names | P12330SCT |
| Operating Temperature | -40°C ~ 85°C | Operating Force | 160/320gf |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mechanical Life | 1,000,000 Cycles | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Ingress Protection | - | Functions, Extra | - |
| Features | - | Electrical Life | 1,000,000 Cycles |
| Detailed Description | Navigation Switch, 2 - Axis Digital (Mechanical Switch) Output | Current Rating | 20mA (DC) |
| Contact Material | - | Contact Finish | - |
| Actuator Type | Tactile (5 Button) |
