ELL-CTV5R6N
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ELL-CTV5R6N with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ELL-CTV5R6N with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ELL-CTV5R6N |
|---|---|
| Manufacturer | Panasonic |
| Description | FIXED IND 5.6UH 4.9A 11 MOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | ||
|---|---|---|---|---|---|
| $0.708 | $0.654 | $0.458 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | ELL-CTV5R6N | Manufacturer | Panasonic |
|---|---|---|---|
| Description | FIXED IND 5.6UH 4.9A 11 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 76234 pcs | Data sheet | ELL-CTV Series |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±30% | Supplier Device Package | - |
| Size / Dimension | 0.472" L x 0.472" W (12.00mm x 12.00mm) | Shielding | Shielded |
| Series | V | Ratings | - |
| Q @ Freq | - | Packaging | Cut Tape (CT) |
| Package / Case | Nonstandard | Other Names | PCD2149CT |
| Operating Temperature | - | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Ferrite |
| Manufacturer Standard Lead Time | 15 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 100kHz | Inductance | 5.6µH |
| Height - Seated (Max) | 0.177" (4.50mm) | Frequency - Self Resonant | - |
| Detailed Description | 5.6µH Shielded Wirewound Inductor 4.9A 11 mOhm Nonstandard | DC Resistance (DCR) | 11 mOhm |
| Current Rating | 4.9A | Current - Saturation | - |
