ELJ-QF2N2ZF
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ELJ-QF2N2ZF with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ELJ-QF2N2ZF with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ELJ-QF2N2ZF |
|---|---|
| Manufacturer | Panasonic |
| Description | FIXED IND 2.2NH 400MA 90 MOHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 10000 pcs | ||||
|---|---|---|---|---|---|
| $0.034 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | ELJ-QF2N2ZF | Manufacturer | Panasonic |
|---|---|---|---|
| Description | FIXED IND 2.2NH 400MA 90 MOHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 711615 pcs | Data sheet | ELJ-QF,QE Series Datasheet |
| Category | Inductors, Coils, Chokes | Type | Multilayer |
| Tolerance | ±0.2nH | Supplier Device Package | 0402 (1005 Metric) |
| Size / Dimension | 0.039" L x 0.020" W (1.00mm x 0.50mm) | Shielding | Unshielded |
| Series | QF | Ratings | - |
| Q @ Freq | 10 @ 100MHz | Packaging | Tape & Reel (TR) |
| Package / Case | 0402 (1005 Metric) | Other Names | ELJQF2N2ZF PCD2396TR |
| Operating Temperature | -40°C ~ 85°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Ceramic |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance Frequency - Test | 100MHz |
| Inductance | 2.2nH | Height - Seated (Max) | 0.022" (0.55mm) |
| Frequency - Self Resonant | 6GHz | Detailed Description | 2.2nH Unshielded Multilayer Inductor 400mA 90 mOhm Max 0402 (1005 Metric) |
| DC Resistance (DCR) | 90 mOhm Max | Current Rating | 400mA |
| Current - Saturation | - |
