ELJ-PB100KF
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ELJ-PB100KF with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ELJ-PB100KF with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ELJ-PB100KF |
|---|---|
| Manufacturer | Panasonic |
| Description | FIXED IND 10UH 360MA 650 MOHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | ELJ-PB100KF | Manufacturer | Panasonic |
|---|---|---|---|
| Description | FIXED IND 10UH 360MA 650 MOHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4000 pcs | Data sheet | ELJ-PF, PE, PC, PA, PB, LC, LA Series |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±10% | Supplier Device Package | 1812 |
| Size / Dimension | 0.177" L x 0.126" W (4.50mm x 3.20mm) | Shielding | Unshielded |
| Series | PB | Ratings | - |
| Q @ Freq | 10 @ 2.52MHz | Packaging | Original-Reel® |
| Package / Case | 1812 (4532 Metric) | Other Names | PCD1522DKR |
| Operating Temperature | -20°C ~ 85°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance Frequency - Test | 2.52MHz |
| Inductance | 10µH | Height - Seated (Max) | 0.134" (3.40mm) |
| Frequency - Self Resonant | 19MHz | Detailed Description | 10µH Unshielded Wirewound Inductor 360mA 650 mOhm Max 1812 (4532 Metric) |
| DC Resistance (DCR) | 650 mOhm Max | Current Rating | 360mA |
| Current - Saturation | - |
