ELF-18D620
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ELF-18D620 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ELF-18D620 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ELF-18D620 |
|---|---|
| Manufacturer | Panasonic |
| Description | CMC 100MH 400MA 2LN TH |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.433 | $1.193 | $1.026 | $1.002 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $0.978 | $0.811 | $0.764 | $0.716 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | ELF-18D620 | Manufacturer | Panasonic |
|---|---|---|---|
| Description | CMC 100MH 400MA 2LN TH | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 51869 pcs | Data sheet | ELF Series, H, F, MELF18D6xxx Spec |
| Category | Filters | Voltage Rating - DC | - |
| Voltage Rating - AC | 250V | Size / Dimension | 1.122" L x 1.142" W (28.50mm x 29.00mm) |
| Series | H | Ratings | - |
| Packaging | Bulk | Package / Case | Vertical, 4 PC Pin |
| Other Names | ELF18D620 PLK1273 |
Operating Temperature | -20°C ~ 105°C |
| Number of Lines | 2 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Inductance @ Frequency | 100mH @ 1kHz | Height (Max) | 0.925" (23.50mm) |
| Filter Type | - | Features | - |
| Detailed Description | 100mH @ 1kHz 2 Line Common Mode Choke Through Hole 400mA DCR 2.448 Ohm (Typ) | DC Resistance (DCR) (Max) | 2.448 Ohm (Typ) |
| Current Rating (Max) | 400mA | Approvals | - |
