EEV-EB2D680M
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy EEV-EB2D680M with confidence from Components-World.HK, 1 Year Warranty
Dowload EEV-EB2D680M Details in PDFSee Product Specifications for product details.
Buy EEV-EB2D680M with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | EEV-EB2D680M |
|---|---|
| Manufacturer | Panasonic |
| Description | CAP ALUM 68UF 20% 200V SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 75 pcs | 150 pcs | 375 pcs | 525 pcs | |
|---|---|---|---|---|---|
| $0.83 | $0.726 | $0.622 | $0.553 | ||
| 750 pcs | 1875 pcs | 3750 pcs | 7500 pcs | ||
| $0.519 | $0.484 | $0.467 | $0.449 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | EEV-EB2D680M | Manufacturer | Panasonic |
|---|---|---|---|
| Description | CAP ALUM 68UF 20% 200V SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 68057 pcs | Data sheet | EEV-EB Series, Type V |
| Category | Capacitors | Voltage - Rated | 200V |
| Tolerance | ±20% | Surface Mount Land Size | 0.669" L x 0.669" W (17.00mm x 17.00mm) |
| Size / Dimension | 0.630" Dia (16.00mm) | Series | EB |
| Ripple Current @ Low Frequency | 412.5mA @ 120Hz | Ripple Current @ High Frequency | 750mA @ 100kHz |
| Ratings | - | Polarization | Polar |
| Packaging | Tape & Reel (TR) | Package / Case | Radial, Can - SMD |
| Other Names | EEVEB2D680M PCE3585TR |
Operating Temperature | -25°C ~ 105°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 21 Weeks | Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Lead Spacing | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height - Seated (Max) | 0.846" (21.50mm) | ESR (Equivalent Series Resistance) | - |
| Detailed Description | 68µF 200V Aluminum Electrolytic Capacitors Radial, Can - SMD 5000 Hrs @ 105°C | Capacitance | 68µF |
| Applications | General Purpose |
