EEH-ZA1J100P
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy EEH-ZA1J100P with confidence from Components-World.HK, 1 Year Warranty
Dowload EEH-ZA1J100P Details in PDFSee Product Specifications for product details.
Buy EEH-ZA1J100P with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | EEH-ZA1J100P |
|---|---|
| Manufacturer | Panasonic |
| Description | CAP ALUM POLY HYB 10UF 63V SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1000 pcs | 2000 pcs | 5000 pcs | 10000 pcs | |
|---|---|---|---|---|---|
| $0.207 | $0.193 | $0.186 | $0.179 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | EEH-ZA1J100P | Manufacturer | Panasonic |
|---|---|---|---|
| Description | CAP ALUM POLY HYB 10UF 63V SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 105754 pcs | Data sheet | EEH-ZA Series, V Type DatasheetZA Series Technical DataHybrid Alum Electrolytic Catalog |
| Category | Capacitors | Voltage - Rated | 63V |
| Type | Hybrid | Tolerance | ±20% |
| Surface Mount Land Size | 0.260" L x 0.260" W (6.60mm x 6.60mm) | Size / Dimension | 0.248" Dia (6.30mm) |
| Series | ZA | Ripple Current @ Low Frequency | 100mA @ 100Hz |
| Ripple Current @ High Frequency | 1A @ 100kHz | Ratings | AEC-Q200 |
| Packaging | Tape & Reel (TR) | Package / Case | Radial, Can - SMD |
| Other Names | EEHZA1J100P P15446TR |
Operating Temperature | -55°C ~ 105°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 13 Weeks | Lifetime @ Temp. | 10000 Hrs @ 105°C |
| Lead Spacing | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height - Seated (Max) | 0.240" (6.10mm) | ESR (Equivalent Series Resistance) | 120 mOhm |
| Detailed Description | 10µF 63V Aluminum Polymer Capacitor Radial, Can - SMD 120 mOhm 10000 Hrs @ 105°C | Capacitance | 10µF |
| Applications | Automotive |
