ECW-U1682JX5
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ECW-U1682JX5 with confidence from Components-World.HK, 1 Year Warranty
Dowload ECW-U1682JX5 Details in PDFSee Product Specifications for product details.
Buy ECW-U1682JX5 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ECW-U1682JX5 |
|---|---|
| Manufacturer | Panasonic |
| Description | CAP FILM 6800PF 5% 100VDC 1210 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $0.291 | $0.214 | $0.147 | $0.116 | $0.098 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | ECW-U1682JX5 | Manufacturer | Panasonic |
|---|---|---|---|
| Description | CAP FILM 6800PF 5% 100VDC 1210 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 226328 pcs | Data sheet | ECW-U1682JX5 View All Specifications |
| Category | Capacitors | Voltage Rating - DC | 100V |
| Voltage Rating - AC | - | Tolerance | ±5% |
| Termination | Solder Pads | Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.50mm) |
| Series | ECW-U(X) | Ratings | - |
| Packaging | Original-Reel® | Package / Case | 1210 (3225 Metric) |
| Other Names | PCF1358DKR | Operating Temperature | -55°C ~ 105°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 4 (72 Hours) |
| Manufacturer Standard Lead Time | 9 Weeks | Lead Spacing | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 0.067" (1.70mm) |
| Features | - | Dielectric Material | Polyester, Polyethylene Naphthalate (PEN), Metallized - Stacked |
| Detailed Description | 6800pF Film Capacitor 100V Polyester, Polyethylene Naphthalate (PEN), Metallized - Stacked 1210 (3225 Metric) | Capacitance | 6800pF |
| Applications | General Purpose |
