BAV99
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy BAV99 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy BAV99 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | BAV99 |
|---|---|
| Manufacturer | Panasonic |
| Description | DIODE ARRAY GP 80V 200MA SOT23-3 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | BAV99 | Manufacturer | Panasonic |
|---|---|---|---|
| Description | DIODE ARRAY GP 80V 200MA SOT23-3 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4665 pcs | Data sheet | BAV99 |
| Category | Discrete Semiconductor Products | Voltage - Forward (Vf) (Max) @ If | 1.25V @ 150mA |
| Voltage - DC Reverse (Vr) (Max) | 80V | Supplier Device Package | SOT-23-3 |
| Speed | Small Signal =< 200mA (Io), Any Speed | Series | - |
| Reverse Recovery Time (trr) | 3ns | Packaging | Tape & Reel (TR) |
| Package / Case | TO-236-3, SC-59, SOT-23-3 | Other Names | BAV99PSTR |
| Operating Temperature - Junction | 150°C (Max) | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Diode Type | Standard | Diode Configuration | 1 Pair Series Connection |
| Detailed Description | Diode Array 1 Pair Series Connection Standard 80V 200mA (DC) Surface Mount TO-236-3, SC-59, SOT-23-3 | Current - Reverse Leakage @ Vr | 100nA @ 80V |
| Current - Average Rectified (Io) (per Diode) | 200mA (DC) | Base Part Number | BAV99 |
