Home > Products > Switches > Snap Action, Limit Switches > AZ47049

AZ47049

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AZ47049 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	AZ47049
Manufacturer	Panasonic
Description	SWITCH SNAP ACTION SPDT 5A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 4503 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	AZ47049	Manufacturer	Panasonic
Description	SWITCH SNAP ACTION SPDT 5A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	4503 pcs	Data sheet	AZ4 Series
Category	Switches	Voltage Rating - DC	30V
Voltage Rating - AC	125V	Termination Style	Cable Leads
Switch Function	On-Mom	Series	AZ4
Release Force	25gf	Pretravel	15°
Packaging	Bulk	Overtravel	-
Other Names	1110-3358	Operating Temperature	-20°C ~ 60°C
Operating Position	-	Operating Force	450gf
Mounting Type	Chassis Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	10,000,000 Cycles	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	IP64 - Dust Tight, Water Resistant	Features	-
Electrical Life	300,000 Cycles	Differential Travel	3°
Current Rating	5A (AC/DC)	Circuit	SPDT
Actuator Type	Side Rotary, Roller
