ALF1P05
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ALF1P05 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ALF1P05 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ALF1P05 |
|---|---|
| Manufacturer | Panasonic |
| Description | RELAY GEN PURPOSE SPST 20A 5V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.366 | $1.282 | $1.14 | $1.083 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.026 | $0.912 | $0.855 | $0.798 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | ALF1P05 | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY GEN PURPOSE SPST 20A 5V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 40306 pcs | Data sheet | ALF Series Datasheet |
| Category | Relays | Turn On Voltage (Max) | 3.5 VDC |
| Turn Off Voltage (Min) | 0.5 VDC | Termination Style | PC Pin |
| Switching Voltage | 250VAC - Max | Series | ALF |
| Release Time | 15ms | Relay Type | General Purpose |
| Packaging | Tube | Operating Temperature | -40°C ~ 60°C |
| Operate Time | 20ms | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | - |
| Detailed Description | General Purpose Relay SPST-NO (1 Form A) 5VDC Coil Through Hole | Contact Rating (Current) | 20A |
| Contact Material | Silver Tin Oxide (AgSnO) | Contact Form | SPST-NO (1 Form A) |
| Coil Voltage | 5VDC | Coil Type | Non Latching |
| Coil Resistance | 27.8 Ohms | Coil Power | 900 mW |
| Coil Current | 180mA |
