ALE72F09
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ALE72F09 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ALE72F09 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ALE72F09 |
|---|---|
| Manufacturer | Panasonic |
| Description | RELAY GEN PURPOSE SPST 16A 9V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 100 pcs | ||||
|---|---|---|---|---|---|
| $0.637 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | ALE72F09 | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY GEN PURPOSE SPST 16A 9V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 60610 pcs | Data sheet | ALE Series Datasheet |
| Category | Relays | Turn On Voltage (Max) | 6.75 VDC |
| Turn Off Voltage (Min) | 0.45 VDC | Termination Style | PC Pin, Quick Connect - 0.187" (4.7mm) |
| Switching Voltage | 277VAC - Max | Series | ALE |
| Release Time | 25ms | Relay Type | General Purpose |
| Packaging | Bulk | Operating Temperature | -40°C ~ 85°C |
| Operate Time | 20ms | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | Insulation - Class F |
| Detailed Description | General Purpose Relay SPST-NO (1 Form A) 9VDC Coil Through Hole | Contact Rating (Current) | 16A |
| Contact Material | Silver Tin Oxide (AgSnO) | Contact Form | SPST-NO (1 Form A) |
| Coil Voltage | 9VDC | Coil Type | Non Latching |
| Coil Resistance | 405 Ohms | Coil Power | 200 mW |
| Coil Current | 22.2mA |
