ALE15B05
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ALE15B05 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ALE15B05 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ALE15B05 |
|---|---|
| Manufacturer | Panasonic |
| Description | RELAY GEN PURPOSE SPST 16A 5V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | ALE15B05 | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY GEN PURPOSE SPST 16A 5V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5441 pcs | Data sheet | ALE Series Datasheet |
| Category | Relays | Turn On Voltage (Max) | 3.75 VDC |
| Turn Off Voltage (Min) | 0.25 VDC | Termination Style | PC Pin |
| Switching Voltage | 277VAC - Max | Series | ALE |
| Release Time | 20ms | Relay Type | General Purpose |
| Packaging | Bulk | Other Names | 255-1992 ALE15B05-ND |
| Operating Temperature | -40°C ~ 85°C | Operate Time | 20ms |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | Insulation - Class B |
| Detailed Description | General Purpose Relay SPST-NO (1 Form A) 5VDC Coil Through Hole | Contact Rating (Current) | 16A |
| Contact Material | Silver Tin Oxide (AgSnO) | Contact Form | SPST-NO (1 Form A) |
| Coil Voltage | 5VDC | Coil Type | Non Latching |
| Coil Resistance | 63 Ohms | Coil Power | 400 mW |
| Coil Current | 80.0mA |
