AHN12012
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AHN12012 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy AHN12012 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | AHN12012 |
|---|---|
| Manufacturer | Panasonic |
| Description | RELAY GEN PURPOSE SPDT 16A 12V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $3.015 | $2.828 | $2.513 | $2.388 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $2.262 | $2.011 | $1.885 | $1.759 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | AHN12012 | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY GEN PURPOSE SPDT 16A 12V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 17552 pcs | Data sheet | HN Relays (AHN) Datasheet |
| Category | Relays | Turn On Voltage (Max) | 8.4 VDC |
| Turn Off Voltage (Min) | 1.2 VDC | Termination Style | Plug In |
| Switching Voltage | 250VAC, 30VDC - Max | Series | AHN |
| Release Time | 5ms | Relay Type | General Purpose |
| Packaging | Tube | Other Names | 255-3337 |
| Operating Temperature | -40°C ~ 50°C | Operate Time | 15ms |
| Mounting Type | Socketable | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | - | Detailed Description | General Purpose Relay SPDT (1 Form C) 12VDC Coil Socketable |
| Contact Rating (Current) | 16A | Contact Material | Silver Nickel (AgNi) |
| Contact Form | SPDT (1 Form C) | Coil Voltage | 12VDC |
| Coil Type | Non Latching | Coil Resistance | 270 Ohms |
| Coil Power | 530 mW | Coil Current | 44.4mA |
