ACNH3112
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ACNH3112 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ACNH3112 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ACNH3112 |
|---|---|
| Manufacturer | Panasonic |
| Description | RELAY AUTOMOTIVE SPST 30A 12V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.74 | $1.632 | $1.45 | $1.378 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.305 | $1.16 | $1.088 | $1.015 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | ACNH3112 | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY AUTOMOTIVE SPST 30A 12V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 38391 pcs | Data sheet | Relay User GuideCN-H Relays (ACNH) |
| Category | Relays | Turn On Voltage (Max) | 5.5 VDC |
| Turn Off Voltage (Min) | 0.8 VDC | Termination Style | PC Pin |
| Switching Voltage | 14VDC - Nom | Series | ACNH |
| Release Time | 10ms | Packaging | Tube |
| Other Names | 255-5271 ACNH3112-ND |
Operating Temperature | -40°C ~ 110°C |
| Operate Time | 10ms | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | Sealed - Fully |
| Contact Rating (Current) | 30A | Contact Material | Silver Alloy, Cadmium Free |
| Contact Form | SPST-NO (1 Form A) | Coil Voltage | 12VDC |
| Coil Type | Non Latching | Coil Resistance | 225 Ohms |
| Coil Power | 640 mW | Coil Current | 53.3mA |
