Home > Products > Isolators > Optoisolators - Transistor, Photovoltaic Output > 4N48UTX

4N48UTX

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 4N48UTX with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	4N48UTX
Manufacturer	Optek Technology / TT Electronics
Description	OPTOISO 1KV TRANS W/BASE 6LCC
Lead Free Status / RoHS Status	Lead free / Not applicable

~~In Stock~~ 6004 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	4N48UTX	Manufacturer	Optek Technology / TT Electronics
Description	OPTOISO 1KV TRANS W/BASE 6LCC	Lead Free Status / RoHS Status	Lead free / Not applicable
Quantity Available	6004 pcs	Data sheet	4N22U-24U, 4N47U-49U
Category	Isolators	Voltage - Output (Max)	45V
Voltage - Isolation	1000VDC	Voltage - Forward (Vf) (Typ)	1.5V (Max)
Vce Saturation (Max)	300mV	Turn On / Turn Off Time (Typ)	-
Supplier Device Package	6-LCC (6.22x4.32)	Series	-
Rise / Fall Time (Typ)	20µs, 20µs	Packaging	Bulk
Package / Case	6-SMD, No Lead	Output Type	Transistor with Base
Operating Temperature	-55°C ~ 125°C	Number of Channels	1
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Lead Free Status / RoHS Status	Lead free / Not applicable	Input Type	DC
Detailed Description	Optoisolator Transistor with Base Output 1000VDC 1 Channel 6-LCC (6.22x4.32)	Current Transfer Ratio (Min)	100% @ 2mA
Current Transfer Ratio (Max)	-	Current - Output / Channel	50mA
Current - DC Forward (If) (Max)	40mA
