2N5794U
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 2N5794U with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 2N5794U with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 2N5794U |
|---|---|
| Manufacturer | Optek Technology / TT Electronics |
| Description | TRANS 2NPN 40V 0.6A 6CLCC |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 1 pcs | 100 pcs | |||
|---|---|---|---|---|---|
| $11.17 | $10.723 | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 2N5794U | Manufacturer | Optek Technology / TT Electronics |
|---|---|---|---|
| Description | TRANS 2NPN 40V 0.6A 6CLCC | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 2861 pcs | Data sheet | 2N5794U(TX,TXV) |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 40V |
| Vce Saturation (Max) @ Ib, Ic | 900mV @ 30mA, 300mA | Transistor Type | 2 NPN (Dual) |
| Supplier Device Package | 6-CLCC | Series | - |
| Power - Max | 600mW | Packaging | Bulk |
| Package / Case | 6-CLCC | Other Names | 2N5794U-ND 365-1986 |
| Operating Temperature | -65°C ~ 200°C (TJ) | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Frequency - Transition | - |
| Detailed Description | Bipolar (BJT) Transistor Array 2 NPN (Dual) 40V 600mA 600mW Surface Mount 6-CLCC | DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 150mA, 10V |
| Current - Collector Cutoff (Max) | 10µA (ICBO) | Current - Collector (Ic) (Max) | 600mA |
