XR2C1011N
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy XR2C1011N with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy XR2C1011N with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | XR2C1011N |
|---|---|
| Manufacturer | Omron |
| Description | CONN SOCKET SIP 10POS GOLD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.659 | $0.597 | $0.561 | $0.536 | $0.512 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $0.463 | $0.427 | $0.366 | $0.352 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | XR2C1011N | Manufacturer | Omron |
|---|---|---|---|
| Description | CONN SOCKET SIP 10POS GOLD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 62672 pcs | Data sheet | XR2 Series |
| Category | Connectors, Interconnects | Type | SIP |
| Termination Post Length | 0.138" (3.50mm) | Termination | Solder |
| Series | XR2 | Pitch - Post | 0.100" (2.54mm) |
| Pitch - Mating | 0.100" (2.54mm) | Packaging | Bulk |
| Other Names | XR2C-1011-N XR2C1011N-ND Z8779 |
Operating Temperature | -55°C ~ 125°C |
| Number of Positions or Pins (Grid) | 10 (1 x 10) | Mounting Type | Threaded |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Housing Material | Polybutylene Terephthalate (PBT), Glass Filled | Features | - |
| Current Rating | 1A | Contact Resistance | 20 mOhm |
| Contact Material - Post | Brass | Contact Material - Mating | Beryllium Copper |
| Contact Finish Thickness - Post | 10.0µin (0.25µm) | Contact Finish Thickness - Mating | 10.0µin (0.25µm) |
| Contact Finish - Post | Gold | Contact Finish - Mating | Gold |
