RA-T2X-25E
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RA-T2X-25E with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy RA-T2X-25E with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | RA-T2X-25E |
|---|---|
| Manufacturer | Ohmite |
| Description | HEATSINK FOR TO-220 218 247 1.0" |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.695 | $0.676 | $0.658 | $0.622 | $0.585 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.548 | $0.53 | $0.475 | $0.466 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | RA-T2X-25E | Manufacturer | Ohmite |
|---|---|---|---|
| Description | HEATSINK FOR TO-220 218 247 1.0" | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 79157 pcs | Data sheet | F,R Series |
| Category | Fans, Thermal Management | Width | 0.985" (25.00mm) |
| Type | Board Level, Vertical | Thermal Resistance @ Natural | 4.80°C/W |
| Thermal Resistance @ Forced Air Flow | 1.50°C/W @ 200 LFM | Shape | Rectangular, Fins |
| Series | R | Power Dissipation @ Temperature Rise | 2.0W @ 20°C |
| Package Cooled | TO-218, TO-220, TO-247 | Other Names | RAT2X25E |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Finish | Black Anodized |
| Material | Aluminum | Manufacturer Standard Lead Time | 17 Weeks |
| Length | 1.654" (42.00mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Off Base (Height of Fin) | 1.000" (25.40mm) | Diameter | - |
| Detailed Description | Heat Sink TO-218, TO-220, TO-247 Aluminum 2.0W @ 20°C Board Level, Vertical | Attachment Method | Bolt On and PC Pin |
