R2V-CT4-38E
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy R2V-CT4-38E with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy R2V-CT4-38E with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | R2V-CT4-38E |
|---|---|
| Manufacturer | Ohmite |
| Description | HEATSINK FOR TO-247 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.142 | $1.111 | $1.081 | $1.021 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $0.961 | $0.901 | $0.871 | $0.78 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | R2V-CT4-38E | Manufacturer | Ohmite |
|---|---|---|---|
| Description | HEATSINK FOR TO-247 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 47393 pcs | Data sheet | R2 Series |
| Category | Fans, Thermal Management | Width | 1.380" (35.05mm) |
| Type | Board Level | Thermal Resistance @ Natural | 9.80°C/W |
| Thermal Resistance @ Forced Air Flow | 1.00°C/W @ 800 LFM | Shape | Rectangular, Fins |
| Series | R2 | Power Dissipation @ Temperature Rise | 2.0W @ 20°C |
| Package Cooled | TO-247 | Other Names | R2VCT438E |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Finish | Degreased |
| Material | Aluminum | Manufacturer Standard Lead Time | 20 Weeks |
| Length | 1.500" (38.10mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Off Base (Height of Fin) | 0.870" (22.10mm) | Diameter | - |
| Detailed Description | Heat Sink TO-247 Aluminum 2.0W @ 20°C Board Level | Attachment Method | Clip and PC Pin |
