8P1P00317BGL421
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 8P1P00317BGL421 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 8P1P00317BGL421 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 8P1P00317BGL421 |
|---|---|
| Manufacturer | NorComp |
| Description | CONN PLUG MALE 3POS SOLDER CUP |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 1 pcs | 18 pcs | 36 pcs | 54 pcs | |
|---|---|---|---|---|---|
| $5.639 | $5.125 | $4.997 | $4.613 | ||
| 108 pcs | 252 pcs | 504 pcs | 1008 pcs | ||
| $4.357 | $3.972 | $3.716 | $3.408 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 8P1P00317BGL421 | Manufacturer | NorComp |
|---|---|---|---|
| Description | CONN PLUG MALE 3POS SOLDER CUP | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 10452 pcs | Data sheet | 8P1Pyyy17ByLyy1 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 500V |
| Termination | Solder Cup | Shielding | Unshielded |
| Shell Size, MIL | - | Shell Size - Insert | - |
| Shell Material | Polyacrylonitrile Butadiene Styrene (ABS), Polycarbonate (PC) | Shell Finish | - |
| Series | QUIK-LOQ™ 8P1P | Packaging | Tray |
| Other Names | NOR1640 | Orientation | Keyed |
| Operating Temperature | -20°C ~ 120°C | Number of Positions | 3 |
| Mounting Type | Free Hanging (In-Line) | Mounting Feature | - |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | - |
| Manufacturer Standard Lead Time | 14 Weeks | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Insert Material | Polyphenylene Sulfide (PPS) | Ingress Protection | IP50 - Dust Protected |
| Features | Backshell, Strain Relief | Fastening Type | Push-Pull |
| Detailed Description | 3 Position Circular Connector Plug, Male Pins Solder Cup Gold | Current Rating | 10A |
| Contact Material | Copper Alloy | Contact Finish Thickness - Mating | 7.00µin (0.178µm) |
| Contact Finish - Mating | Gold | Connector Type | Plug, Male Pins |
| Color | Gray | Cable Opening | 0.087" ~ 0.157" (2.20mm ~ 3.99mm) |
| Backshell Material, Plating | Polyacrylonitrile Butadiene Styrene (ABS), Polycarbonate (PC) | Applications | - |
