ESMH160VSN104MA80T
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ESMH160VSN104MA80T with confidence from Components-World.HK, 1 Year Warranty
Dowload ESMH160VSN104MA80T Details in PDFSee Product Specifications for product details.
Buy ESMH160VSN104MA80T with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ESMH160VSN104MA80T |
|---|---|
| Manufacturer | Nippon Chemi-Con |
| Description | CAP ALUM 100000UF 20% 16V SNAP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $3.252 | $2.891 | $2.313 | $1.987 | $1.872 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | ESMH160VSN104MA80T | Manufacturer | Nippon Chemi-Con |
|---|---|---|---|
| Description | CAP ALUM 100000UF 20% 16V SNAP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 19418 pcs | Data sheet | SMH Series Bulletin |
| Category | Capacitors | Voltage - Rated | 16V |
| Tolerance | ±20% | Surface Mount Land Size | - |
| Size / Dimension | 1.378" Dia (35.00mm) | Series | SMH |
| Ripple Current @ Low Frequency | 11.67A @ 120Hz | Ripple Current @ High Frequency | 12.6036A @ 100kHz |
| Ratings | - | Polarization | Polar |
| Packaging | Bulk | Package / Case | Radial, Can - Snap-In |
| Other Names | 565-2624 ESMH160VSN104MA80N |
Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Through Hole | Manufacturer Standard Lead Time | 16 Weeks |
| Lifetime @ Temp. | 2000 Hrs @ 85°C | Lead Spacing | 0.394" (10.00mm) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | - |
| ESR (Equivalent Series Resistance) | 9 mOhm @ 120Hz | Detailed Description | 100000µF 16V Aluminum Electrolytic Capacitors Radial, Can - Snap-In 9 mOhm @ 120Hz 2000 Hrs @ 85°C |
| Capacitance | 100000µF | Applications | General Purpose |
