EKMG630ETD221MJ16S
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy EKMG630ETD221MJ16S with confidence from Components-World.HK, 1 Year Warranty
Dowload EKMG630ETD221MJ16S Details in PDFSee Product Specifications for product details.
Buy EKMG630ETD221MJ16S with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | EKMG630ETD221MJ16S |
|---|---|
| Manufacturer | Nippon Chemi-Con |
| Description | CAP ALUM 220UF 20% 63V RADIAL |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 800 pcs | 1600 pcs | 2400 pcs | 4000 pcs | |
|---|---|---|---|---|---|
| $0.083 | $0.078 | $0.073 | $0.068 | ||
| 8000 pcs | 20000 pcs | 40000 pcs | |||
| $0.066 | $0.065 | $0.063 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | EKMG630ETD221MJ16S | Manufacturer | Nippon Chemi-Con |
|---|---|---|---|
| Description | CAP ALUM 220UF 20% 63V RADIAL | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 333259 pcs | Data sheet | KMG Series Datasheet |
| Category | Capacitors | Voltage - Rated | 63V |
| Tolerance | ±20% | Surface Mount Land Size | - |
| Size / Dimension | 0.394" Dia (10.00mm) | Series | KMG |
| Ripple Current @ Low Frequency | 335mA @ 120Hz | Ripple Current @ High Frequency | 502.5mA @ 100kHz |
| Ratings | - | Polarization | Polar |
| Packaging | Tape & Box (TB) | Package / Case | Radial, Can |
| Other Names | 565-3746-2 565-3746-2-ND 565-3746-3 EKMG630ETD221MJ16S-ND |
Operating Temperature | -55°C ~ 105°C |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 16 Weeks | Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Lead Spacing | 0.197" (5.00mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height - Seated (Max) | 0.689" (17.50mm) | ESR (Equivalent Series Resistance) | - |
| Detailed Description | 220µF 63V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C | Capacitance | 220µF |
| Applications | General Purpose |
