Home > Products > Capacitors > Aluminum Electrolytic Capacitors > USF1A680MDD

USF1A680MDD

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy USF1A680MDD with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	USF1A680MDD
Manufacturer	Nichicon
Description	CAP ALUM 68UF 20% 10V RADIAL
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	1000 pcs	2500 pcs	5000 pcs
~~In Stock~~ 523839 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	100 pcs	500 pcs
	$0.169	$0.118	$0.071	$0.053
	$0.045	$0.042	$0.04

Product parameter
Data sheet

Product parameter

Part Number	USF1A680MDD	Manufacturer	Nichicon
Description	CAP ALUM 68UF 20% 10V RADIAL	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	523839 pcs	Data sheet	USF Series Miniature Type Taping Spec
Category	Capacitors	Voltage - Rated	10V
Tolerance	±20%	Surface Mount Land Size	-
Size / Dimension	0.248" Dia (6.30mm)	Series	USF
Ripple Current @ Low Frequency	80mA @ 120Hz	Ripple Current @ High Frequency	160mA @ 100kHz
Ratings	-	Polarization	Polar
Packaging	Bulk	Package / Case	Radial, Can
Other Names	493-6013 USF1A680MDD-ND	Operating Temperature	-55°C ~ 105°C
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	21 Weeks	Lifetime @ Temp.	1000 Hrs @ 105°C
Lead Spacing	0.098" (2.50mm)	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Impedance	800 mOhms	Height - Seated (Max)	0.315" (8.00mm)
ESR (Equivalent Series Resistance)	-	Detailed Description	68µF 10V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C
Capacitance	68µF	Applications	General Purpose
