Home > Products > Capacitors > Aluminum Electrolytic Capacitors > UCS2V680MHD

UCS2V680MHD

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy UCS2V680MHD with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	UCS2V680MHD
Manufacturer	Nichicon
Description	CAP ALUM 68UF 20% 350V RADIAL
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	1000 pcs	2500 pcs	5000 pcs
~~In Stock~~ 91490 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	100 pcs	500 pcs
	$0.665	$0.526	$0.394	$0.298
	$0.263	$0.245	$0.236

Product parameter
Data sheet

Product parameter

Part Number	UCS2V680MHD	Manufacturer	Nichicon
Description	CAP ALUM 68UF 20% 350V RADIAL	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	91490 pcs	Data sheet	Chip Type Tape Spec UCS Series Datasheet
Category	Capacitors	Voltage - Rated	350V
Tolerance	±20%	Surface Mount Land Size	-
Size / Dimension	0.630" Dia (16.00mm)	Series	UCS
Ripple Current @ Low Frequency	700mA @ 120Hz	Ripple Current @ High Frequency	1.4A @ 100kHz
Ratings	-	Polarization	Polar
Packaging	Bulk	Package / Case	Radial, Can
Other Names	493-14945 UCS2V680MHD-ND	Operating Temperature	-40°C ~ 105°C
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	Not Applicable
Manufacturer Standard Lead Time	33 Weeks	Lifetime @ Temp.	10000 Hrs @ 105°C
Lead Spacing	0.295" (7.50mm)	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Height - Seated (Max)	1.043" (26.50mm)	ESR (Equivalent Series Resistance)	-
Detailed Description	68µF 350V Aluminum Electrolytic Capacitors Radial, Can 10000 Hrs @ 105°C	Capacitance	68µF
Applications	General Purpose
