Home > Products > Capacitors > Aluminum Electrolytic Capacitors > UCS2D220MPD1TD

UCS2D220MPD1TD

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy UCS2D220MPD1TD with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	UCS2D220MPD1TD
Manufacturer	Nichicon
Description	CAP ALUM 22UF 20% 200V RADIAL
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	12500 pcs	25000 pcs	50000 pcs
~~In Stock~~ 367718 pcs
Reference Price (In US Dollars)	500 pcs	1000 pcs	2500 pcs	5000 pcs
	$0.081	$0.069	$0.065	$0.061
	$0.056	$0.055	$0.053

Product parameter
Data sheet

Product parameter

Part Number	UCS2D220MPD1TD	Manufacturer	Nichicon
Description	CAP ALUM 22UF 20% 200V RADIAL	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	367718 pcs	Data sheet	Chip Type Tape Spec UCS Series Datasheet
Category	Capacitors	Voltage - Rated	200V
Tolerance	±20%	Surface Mount Land Size	-
Size / Dimension	0.394" Dia (10.00mm)	Series	UCS
Ripple Current @ Low Frequency	250mA @ 120Hz	Ripple Current @ High Frequency	500mA @ 100kHz
Ratings	-	Polarization	Polar
Packaging	Tape & Box (TB)	Package / Case	Radial, Can
Other Names	493-7382-2 493-7382-2-ND 493-7382-3	Operating Temperature	-40°C ~ 105°C
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	Not Applicable
Manufacturer Standard Lead Time	26 Weeks	Lifetime @ Temp.	8000 Hrs @ 105°C
Lead Spacing	0.197" (5.00mm)	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Height - Seated (Max)	0.866" (22.00mm)	ESR (Equivalent Series Resistance)	-
Detailed Description	22µF 200V Aluminum Electrolytic Capacitors Radial, Can 8000 Hrs @ 105°C	Capacitance	22µF
Applications	General Purpose
