Home > Products > Capacitors > Aluminum Electrolytic Capacitors > UBX1H561MHL

UBX1H561MHL

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy UBX1H561MHL with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	UBX1H561MHL
Manufacturer	Nichicon
Description	CAP ALUM 560UF 20% 50V RADIAL
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	1000 pcs	2500 pcs	5000 pcs
~~In Stock~~ 71689 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	100 pcs	500 pcs
	$1.161	$0.939	$0.717	$0.546
	$0.478	$0.461	$0.444

Product parameter
Data sheet

Product parameter

Part Number	UBX1H561MHL	Manufacturer	Nichicon
Description	CAP ALUM 560UF 20% 50V RADIAL	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	71689 pcs	Data sheet	UBX Series Miniature Type Taping Spec
Category	Capacitors	Voltage - Rated	50V
Tolerance	±20%	Surface Mount Land Size	-
Size / Dimension	0.492" Dia (12.50mm)	Series	UBX
Ripple Current @ Low Frequency	540mA @ 120Hz	Ripple Current @ High Frequency	1.08A @ 100kHz
Ratings	-	Polarization	Polar
Packaging	Bulk	Package / Case	Radial, Can
Other Names	493-13054 UBX1H561MHL-ND	Operating Temperature	-55°C ~ 150°C
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	22 Weeks	Lifetime @ Temp.	1000 Hrs @ 150°C
Lead Spacing	0.197" (5.00mm)	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Height - Seated (Max)	1.299" (33.00mm)	ESR (Equivalent Series Resistance)	-
Detailed Description	560µF 50V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 150°C	Capacitance	560µF
Applications	Automotive
