PMDXB950UPELZ
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PMDXB950UPELZ with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PMDXB950UPELZ with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PMDXB950UPELZ |
|---|---|
| Manufacturer | Nexperia |
| Description | 20 V, DUAL P-CHANNEL TRENCH MOSF |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $0.177 | $0.139 | $0.095 | $0.065 | $0.049 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | PMDXB950UPELZ | Manufacturer | Nexperia |
|---|---|---|---|
| Description | 20 V, DUAL P-CHANNEL TRENCH MOSF | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 419756 pcs | Data sheet | PMDXB950UPEL |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 950mV @ 250µA |
| Supplier Device Package | DFN1010B-6 | Series | - |
| Rds On (Max) @ Id, Vgs | 1.4 Ohm @ 500mA, 4.5V | Power - Max | 380mW |
| Packaging | Original-Reel® | Package / Case | 6-XFDFN Exposed Pad |
| Other Names | 1727-2601-6 568-13060-6 568-13060-6-ND |
Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 8 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 43pF @ 10V | Gate Charge (Qg) (Max) @ Vgs | 2.1nC @ 4.5V |
| FET Type | 2 P-Channel (Dual) | FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 20V | Detailed Description | Mosfet Array 2 P-Channel (Dual) 20V 500mA 380mW Surface Mount DFN1010B-6 |
| Current - Continuous Drain (Id) @ 25°C | 500mA |
