PMCM440VNEZ
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PMCM440VNEZ with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PMCM440VNEZ with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PMCM440VNEZ |
|---|---|
| Manufacturer | Nexperia |
| Description | MOSFET N-CH 12V 4WLCSP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 9000 pcs | ||||
|---|---|---|---|---|---|
| $0.036 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | PMCM440VNEZ | Manufacturer | Nexperia |
|---|---|---|---|
| Description | MOSFET N-CH 12V 4WLCSP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 654629 pcs | Data sheet | PMCM440VNE |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 900mV @ 250µA |
| Vgs (Max) | ±8V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | 4-WLCSP (0.78x0.78) | Series | - |
| Rds On (Max) @ Id, Vgs | 67 mOhm @ 3A, 4.5V | Power Dissipation (Max) | 400mW (Ta), 12.5W (Tc) |
| Packaging | Tape & Reel (TR) | Package / Case | 4-XFBGA, WLCSP |
| Other Names | 1727-2274-2 568-12560-2 568-12560-2-ND 934068625084 |
Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Ciss) (Max) @ Vds | 360pF @ 6V |
| Gate Charge (Qg) (Max) @ Vgs | 8.2nC @ 4.5V | FET Type | N-Channel |
| FET Feature | - | Drive Voltage (Max Rds On, Min Rds On) | 4.5V |
| Drain to Source Voltage (Vdss) | 12V | Detailed Description | N-Channel 12V 3.9A (Ta) 400mW (Ta), 12.5W (Tc) Surface Mount 4-WLCSP (0.78x0.78) |
| Current - Continuous Drain (Id) @ 25°C | 3.9A (Ta) |
